Caratteristiche Tecniche
| CPU | 11th Generation Intel® BGA processor |
|---|---|
| Chipset | Intel® W580 |
| RAM | 2 x 260-pin SO-DIMM up to 64GB (32GB per slot) Dual channel DDR4 up to 3200MHz (Support in-band ECC) |
| LAN | 2 x Intel® I211AT/I210IT PCIe (10/100/1000 Mbps), 1 x Intel® I225LM/I225IT PCIe (10/100/1000 Mbps/2,5 Gbps) |
| I/O | 4 x USB 3.1 Gen2, 1 x USB tipo C, 2x RS-232/422/485, 2x RS-232 |
| Storage | 1 x M.2 2242/2280 M Key (PCIe Gen4 x4) (Support NVMe and Intel® Optane memory), 1 x M.2 2242/3042/3052 B Key (PCIe Gen3 x1/SATA/USB 3.1 Gen1) (Support 4G/5G and storage module), 2 x SATA 3.0 (up to 6Gb/s) (RAID 0/1) |
| Expansion | 1 x PCIe x4 (PCIe Gen 3 x4), 1 x M.2 2230 E Key (USB2.0) (Support Intel® CNVi module only and Intel® vPro), 1 x Nano-SIM Socket (Connect to M.2 Key B for 4G/5G module) |
| Operative range | -5 ~ 65°C / -20 ~ 70°C |
| Power | Wide Range 9 ~ 36V |
| Notes | CE, FCC, RoHS, UKCA |
