Caratteristiche generali
CPU | 8M Quad (4 x Cortex-A53 @ 1.3GHz) / 8M Dual (2 x Cortex-A53 @ 1.3GHz) |
---|---|
Chipset | – |
RAM | LPDDR4 Onboard Memory with Options: 1GB (1200MHz), 2GB (1600MHz), 4GB (1600MHz) |
LAN | 2 x GigE RJ45 |
I/O | 2 x USB 3.0, 1 x USB 2.0, 1 x USB OTG, 1 x RS-232/422/485, 1 x 10bit GPIO |
Storage | Onboard eMMC with Options for 8GB / 16GB / 32GB, 1 x Micro SD card slot (Up to 256GB) |
Expansion | 1 x mPCIe |
Operative range | -10°C to 65°C |
Power | 12V DC Input |
Notes | – |
