General Features
| CPU | NXP i.MX 8M Dual/Quad Cortex-A53 |
|---|---|
| Chipset | – |
| RAM | Single channel soldered LPDDR4 3200MHz, up to 4GB |
| LAN | 1 x GigE RJ45 |
| I/O | 1 x USB 3.1 (Gen 1), 4 x USB 2.0, 1 x COM (RS485), 1 x COM (RS232/422/485), 1 x COM (RS232), 1 x 8bit DIO |
| Storage | eMMC up to 64GB, 1 x microSD slot |
| Expansion | 1 x M.2 Key B, 1 x M.2 Key E |
| Operative range | -5 °C to 65 °C |
| Power | 12V DC |
| Notes | – |
