Caratteristiche Tecniche
| CPU | Intel LGA4677 Socket supports 4th/5th Generation Intel® Xeon® Scalable Processor (Max. TDP at 270W) |
|---|---|
| Chipset | Intel® C741 Chipset |
| RAM | 6 x DDR5 5600 MHz RDIMM up to 1.5TB |
| LAN | 5 x RJ45: 1 x MGMT port for dedicated IPMI access only; 1 x LAN1 port for 1GbE shared with IPMI access; 1 x LAN2 port for 2.5GbE; 2 x LAN3 and 4 ports for 10GbE |
| I/O | 2 x USB 2.0 ports; 4 x USB 3.2 Gen1 ports; 4 x USB 3.2 Gen1 internal ports; 1 x RS232 port; 1 x VGA |
| Storage | 5 x SATA III (Note:SATA 1~4 support RAID 0,1,5,10); 1 x M.2 M-Key PCIe 3.0 x4 NVMe SSD, 2242/2260/2280/22110 form factor |
| Expansion | 4 x PCIe Gen5 x16 slots; 3 x PCIe Gen5 x4 slots Slot 1, PCIe 5.0 x16 Slot 2, PCIe 5.0 x4 Slot 3, PCIe 5.0 x16 Slot 4, PCIe 5.0 x4 Slot 5, PCIe 5.0 x16 Slot 6, PCIe 5.0 x4 Slot 7, PCIe 5.0 x16 (Slot 7 is the slot closest to CPU) |
| Operative range | 0° ÷ 55°C to support up to 250W TDP CPU 0° ÷ 45°C to support up to 270W TDP CPU |
| Power | ATX |
| Notes |
