Caratteristiche Tecniche
| CPU | Onboard Intel® Pentium®/Celeron®/Atom™ SoC BGA Processor (Elkhart Lake Platform 4.5~12W)-(with CPU Bottom Mounted) |
|---|---|
| Chipset | – |
| RAM | Onboard Single channel LPDDR4 4GB memory down (8GB for BOM option) |
| LAN | 1 x Intel® I210AT/IT Gigabit Ethernet |
| I/O | 2 x USB 3.1 Gen2 at I/O, 4 x USB2.0 fby pin header, 1 x RS232/422/485, 1 x 8-bit GPIO |
| Storage | 1 x M.2 Type B |
| Expansion | 1 x M.2 Type B 3042/2242 bridge bracket to 3052 (with PCI-e x2 (via OEM BIOS request) or default (PCI-e x1+USB2.0/USB3.0), or (SATAIII+ USB2.0/USB3.0), SIM Slot for SSD/LTE/IO Cards) *Default is PCI-e x1/SATAIII+USB2.0/USB3.0 support WWAN+GNSS or NVMe SSD |
| Operative range | 0~60°C |
| Power | DC in +12V |
| Notes | – |
