Caratteristiche Tecniche
| CPU | Intel® Atom® x6000E Series and Celeron® Series processors |
|---|---|
| Chipset | – |
| RAM | 1 x 260-pin DDR4 2666MHz SO-DIMM supports up to 32GB |
| LAN | 2 x Intel® i226LM/IT 2.5G Gigabit Ethernet |
| I/O | 4 x USB 2.0 by pin header, 1 x dual stack USB 3.1 Gen2 at I/O 1 x 4-bit GPIO, 1 x RS232, 1 x RS232/422/485″ |
| Storage | 1 x M.2 Type B 2242/2260 with (1 x PCI-e x2 via OEM BIOS request) or (1 x PCI-e x1 + USB3.1 GEN 1)-Default or (1 x SATA III + USB3.1 GEN) |
| Expansion | 1 x M.2 Type B 2242/2260 with (1 x PCI-e x2 via OEM BIOS request) or (1 x PCI-e x1 + USB3.1 GEN 1)-Default or (1 x SATA III + USB3.1 GEN) |
| Operative range | 0~60°C (32~140°F) Elkhart Lake J Series CPU SKU -20~60°C (-4~140°F) Elkhart Lake Atom Series CPU SKU w/HDD/SSD, ambient with 0.5 m/s Air flow |
| Power | 12V |
| Notes | – |
