Caratteristiche Tecniche
| CPU | Intel® Atom® x6000E and Celeron® Processor |
|---|---|
| Chipset | – |
| RAM | 1 x SO-DIMM 260 PIN DDR4 3200MHz up to 32GB |
| LAN | 4 x Intel® i225/i226LM/IT(Default: i226LM/IT); (I225/i226IT for wide temp version) 2.5 Gigabit Ethernet (BOM optional for 1 x 2 RJ45 Thin Mini ITX Cost version design SKU) |
| I/O | 2 x USB3.1 Gen2 and 2 x USB3.1 Gen1 at I/O, 4 x USB 2.0 by pin header, 4 x RS232, 2 x RS-232/RS422/485, 1 x 16-bit GPIO |
| Storage | 1 x M.2 Type B slot for 3042/3052/2242/2260/2280 size with SATAIII + USB 3.1 GEN2, USB 2.0, SIM Slot for SSD/LTE/IO Cards support WWAN+GNSS and SSD, 2 x SATA III |
| Expansion | 1 x M.2 Key E 2230 support WiFi module (1 x PCI-e x1 & USB 2.0 Signal) |
| Operative range | 0 ~ 60°C (32 ~ 140 °F) Intel® Pentium®/Celeron®N/J Series CPU SKU -20 ~ 60°C (-8~140°F) Intel® Atom®x6000 Series CPU SKU |
| Power | DC +12V ~ 24V |
| Notes | – |
