General Features
| CPU | Quad Core Intel® Core™ i7/i5/i3 Processor (Tiger Lake UP3) |
|---|---|
| Chipset | – |
| RAM | Single Channel DDR4 SO-DIMM 3200MHz, up to 32GB |
| LAN | 1 x GigE RJ45, 1 x 2.5G RJ45 |
| I/O | 2 x USB 3.1 Gen 1, 6 x USB 2.0, 4 x RS-232/422/485 |
| Storage | 2 x SATA (6 Gb/s), 1 x M.2 Key B |
| Expansion | 1 x M.2 Key B, 1 x M.2 Key E |
| Operative range | -40°C to 85°C |
| Power | 9V to 55V Wide Range DC Input, Ignition Control |
| Notes | – |
