Caratteristiche Tecniche
| CPU | Intel Atom® X Series Processors Elkhart Lake |
|---|---|
| Chipset | – |
| RAM | Two 260-pin SODIMM up to 32GB,Dual channel DDR4 up to 3200MHz |
| LAN | 2 x Intel® I225LM (10/100/1000/2500Mbps) |
| I/O | 2 x USB 3.2 Gen2, 2 x USB 3.2 Gen1, 4 x USB 2.0 (Internal), 2 x USB 2.0 (Internal), 1 x Vertical USB 2.0 (type A) (opt., MOQ required), 2 X RS-232/422/485, 4 x RS-232 |
| Storage | 2 x SATA 3.0 (up to 6Gb/s) (one SATA port shared with M.2 B key) |
| Expansion | 1 x PCIe x4 (Default: PCIe x1 signal with M.2 B key active/ Opt: PCIe x2 signal with M.2 B key inactive), 1 x M.2 2242/2280/3052 B Key (PCIe x1/SATA/USB2.0), 1 x M.2 2230 E Key (PCIe x1/USB2.0), 1 x Nano SIM socket (connected to M.2 B key) |
| Operative range | -5°C to 65°C, -40°C to 85°C (Opzionale) |
| Power | Wide Range 9~36V (4P vertical type by default) |
| Notes | – |
