Caratteristiche generali
| CPU | Intel® 10th Generation Core™ i9/i7/i5/i3/ Pentium®/ Celeron®/ Xeon® W-1200 Series Processor (Max. TDP at 125W) |
|---|---|
| Chipset | Intel® W480E |
| RAM | 4 x 288-pin DDR4 U-DIMM supports up to 128GB (ECC memory supported by CPU) |
| LAN | 3 x GigE RJ45 |
| I/O | 6 x USB 3.1, 2 x USB 2.0, 2 x RS-232/422/485, 6 x RS-232, 1 x 16bit GPIO |
| Storage | 4 x SATA (6 Gb/s), 1 x M.2 Key B |
| Expansion | 2 x PCIe x16 slot for 1 x PCIe x16 or 2 x PCIe x 8(By Auto swith IC), 4 x PCIe x4 |
| Operative range | 0°C to 60°C |
| Power | ATX |
| Notes | – |
