Caratteristiche generali
| CPU | 10th Gen Intel® Xeon/Core™/Pentium/Celeron Processors, LGA 1200 Socket |
|---|---|
| Chipset | Intel® W480, Intel® Q470 |
| RAM | Dual Channel DDR4 SO-DIMM 2933MHz, up to 64GB |
| LAN | 1 x 2.5G RJ45, 2 x GigE RJ45 |
| I/O | 4 x USB 3.2, 4 x USB 2.0, 2 x COM (RS-232/422/485), 2 x COM (RS-232), 1 x 8 bit DIO |
| Storage | 2 x SATA3 (6 Gb/s), 1 x M.2 Key M, 1 x M.2 Key B |
| Expansion | 1 x PCIe x16, 1 x M.2 Key B, 1 x M.2 Key E |
| Operative range | -5°C to 65°C |
| Power | 12V DC Power Input (CMS101), 15V to 36V DC Power Input (CMS103) |
| Notes | – |
