General Features
| CPU | Intel® Xeon® E-2176G/2124G LGA 1151 Socket Processors up to 80W, 8th Generation Intel® Core™ /Pentium®/Celeron® LGA 1151 Socket Processors up to 95W |
|---|---|
| Chipset | Intel® C246 Chipset |
| RAM | Four 288-pin ECC/Non-ECC DIMM up to 64GB, Dual Channel DDR4 2400/2666MHz |
| LAN | 2 x GigE RJ45 |
| I/O | 2 x RS-232/422/485,4 x RS-232, 2 x USB 3.1 Gen2, 4 x USB 3.1 Gen1, 6 x USB 2.0, 1 x 8-bit DIO |
| Storage | 5 x SATA (6 Gb/s), 1 x M.2 Key M |
| Expansion | 2 x PCIe x16, 3 x PCIe x4, 1 x PCIe x 1, 1 x PCI |
| Operative range | 0°C to 60°C |
| Power | ATX |
| Notes | – |
