Caratteristiche Tecniche
| CPU |
Intel Core i3-8145UE (2C/4T,2.2GHz,15W TDP) Intel Core i5-8365UE (4C/8T,1.6GHz,15W TDP) |
|---|---|
| Chipset | Intel SoC |
| RAM | 1 x 260pin SO-DIMM, up to 32G DDR4 2400MHz |
| LAN | 2 x GbE RJ-45 |
| I/O | 4 x USB 3.0 type A; 1 x RS-232 (COM1, 5-pin terminal block); 1 x RS-232/422/485 Selectable Default RS-485 (COM 2, 5-pin terminal block); 1 x Display Port |
| Storage | 1 x M.2 M-Key 2242(option 2280 can’t use TB-528 at same time); 1 x 2.5″ HDD space (option) |
| Expansion | 1 x TB-528 Expansion Connector (for 19”/24” only); option TB-528C2I for Isolation 2 x RS-422/485 Isolation |
| Display Size and Form Factor | 23.8″ TFT-LCD |
| Resolution | 1920 x 1080 px |
| Brightness | 250 cd/m2 |
| Touch | Projected Capacitive Touch |
| Mechanicals | Black/ Aluminum Bezel and Aluminum Housing (Anti-Corrosion Coating); Panel Mount/ VESA Mount Front Access Mount / Mounting Bracket (option) |
| Operating Temperature | 0°÷50°C / -20°÷60°C (option) |
| Power | DC 24V with Isolated / AC Power option |
| Notes | CE/FCC/IEC 60945 |
