Caratteristiche Tecniche
| CPU | Intel Elkhart Lake Celeron J6412, Quad-core 2.0Ghz, burst to 2.6Ghz, TDP 10W |
|---|---|
| Chipset | – |
| RAM | 1 x SO-DIMM, Support DDR4 2666/2933/3200 MHz, Max. up to 32GB |
| LAN |
2 x Intel I225 GBE LAN chip |
| I/O | 3 x USB3.0, 3 x USB2.0, 2 x COM (DB9) (Optional 1 x RS485); |
| Storage | 1 x M.2 2280 (NVMe PCIe 2.0) + 1 x 2.5” SATA |
| Expansion | 1 x M.2 Key-B slot, 1 x Mini-PCIe slot |
| Display Size and Form Factor | 21.5″, – |
| Resolution | 1920 x 1080 px (Full HD) |
| Brightness | 250 cd/m2 |
| Touch | PCAP |
| Mechanicals | IP65 Front Panel,VESA Mount, Panel Mount |
| Operating Temperature | 0 ～ +60℃ |
| Power | DC 12V (Optional DC 9~36V) |
| Notes | CE/FCC Class A |
