Caratteristiche Tecniche
| CPU | Intel 11th Gen. Tiger Lake UP3 |
|---|---|
| Chipset | – |
| RAM | 1 x DDR4 SO-DIMM, Support DDR4 2666/2933/3200 MHz, Max. up to 32GB |
| LAN | 2 x RJ45, 10/100/1000 Mbps |
| I/O | 6 x USB 3.0, 2 x RS232 (Optional 1* RS485), 2 x HDMI |
| Storage | 1 x M.2 2280 (PCIe NVMe) SSD, 1 x 2.5” SATA SSD |
| Expansion | 1 x M.2 (NGFF) Key-B 3042/3052 slot, 1 x M.2 (NGFF) Key-E 2230 slot |
| Display Size and Form Factor | 17.0″ , – |
| Resolution | 1280 x 1024 px |
| Brightness | 250 cd/m2 |
| Touch | PCAP |
| Mechanicals | IP65 Front Panel,VESA Mount, Panel Mount |
| Operating Temperature | 0°C to 50°C |
| Power | DC 12V (Optional DC 9~36V) |
| Notes | CE/FCC Class A |
