Caratteristiche Tecniche
| CPU | 11th Gen. Intel Core i3/i5 Processor |
|---|---|
| Chipset | – |
| RAM | 2 x 260Pin SO-DIMM DDR4 slot, up to 64GB 3200MHz |
| LAN | 2 x GbE LAN RJ-45 |
| I/O |
4 x USB 3.0 type A, 1 x DB-9 connector, including: * 1 x RS-232(RTS, Rx, Tx, CTS), pin1 RTS/5V/12V selectable via jumper (COM1) * 1 x RS-232(Tx, Rx)/422/485(COM2) by Y Cable |
| Storage | 1 x M.2 M-Key 2280 (Support PCIe/SATA3) |
| Expansion | 1 x Mini-PCIe slot (full size), 1 x M.2 E key for Wifi/BT Module, 1 x Nano SIM slot |
| Display Size and Form Factor | 21.5″, – |
| Resolution | 1920 x 1080 px |
| Brightness | 250 cd/m2 |
| Touch | PCAP |
| Mechanicals | IP66 compliant front bezel ,VESA 100×100, Panel Mount |
| Operating Temperature | 0~50˚C / -20~60˚C (option) |
| Power | DC 9~36V |
| Notes | CE/FCC, Class A |
