Caratteristiche Tecniche
| CPU | Freescale i.MX6 Dual Lite, ARM Cortex A9(2x Cores,1.0GHz) |
|---|---|
| Chipset | – |
| RAM | Onboard 1GB DDR3 DRAM |
| LAN | 1 x GbE LAN RJ-45 |
| I/O | 2 x USB 2.0 type A; 1 x USB 2.0 (Micro B Type) Serial / Parallel; 1 x RS-232/422/485 DB9, default RS-232 |
| Storage | Onboard 4GB eMMC NAND Flash |
| Expansion | 1 x mini-PCIe slot(full size); 1 x Sim Card slot |
| Display Size and Form Factor | 21.5″ TFT-LCD |
| Resolution | 1920 x 1080 px |
| Brightness | 250 cd/m2 |
| Touch |
Resistive Touch (for R Model) Projected Capacitive Touch (for P Model) Glass (for G model) |
| Mechanicals | IP66 compliant front bezel; Aluminum die-casting Chassis; VESA Mount 100×100; Panel Mount |
| Operating Temperature | 0°÷50°C |
| Power | DC 12÷36V |
| Notes | CE/FCC Class A |
