Caratteristiche Tecniche
| CPU | Freescale i.MX6 Dual Lite, ARM Cortex A9(2x Cores,1.0GHz) |
|---|---|
| Chipset | – |
| RAM | Onboard 1GB DDR3 DRAM |
| LAN | 1 x GbE LAN RJ-45 |
| I/O | 2 x USB 2.0 type A; 1 x USB 2.0 (Micro B Type) Serial / Parallel; 1 x RS-232/422/485 DB9, default RS-232 |
| Storage | Onboard 4GB eMMC NAND Flash |
| Expansion | 1 x mini-PCIe slot(full size); 1 x Sim Card slot |
| Display Size and Form Factor | 8″ TFT-LCD |
| Resolution | 800 x 600 px |
| Brightness | 350 cd/m2 |
| Touch |
Resistive Touch (for R Model) Projected Capacitive Touch (for P Model) Glass (for G model) |
| Mechanicals | IP65 compliant front bezel; Plastic front bezel and Chassis; VESA Mount 100×100; Panel Mount |
| Operating Temperature | 0°÷50°C -20°÷60°C (option) |
| Power | DC 9÷36V |
| Notes | CE/FCC Class A |
