Caratteristiche Tecniche
| CPU | Freescale i.MX6 Dual Lite, ARM Cortex A9(2x Cores,1.0GHz) |
|---|---|
| Chipset | – |
| RAM | Freescale i.MX6 Dual Lite, ARM Cortex A9(2x Cores,1.0GHz) |
| LAN | 1 x GbE LAN RJ-45 (PoE for option) |
| I/O | 2 x USB 2.0 type A 1 x USB 2.0 (Micro B Type) Serial / Parallel 1 x RS-232/422/485 DB9 , default RS-232 |
| Storage | Onboard 4GB eMMC NAND Flash |
| Expansion | 1 x mini-PCIe slot(full size) |
| Display Size and Form Factor | 7″, – |
| Resolution | 800 x 480 px |
| Brightness | 350 cd/m2 |
| Touch | PCAP |
| Mechanicals | IP65 compliant front bezel,VESA Mount 75×75, Panel Mount |
| Operating Temperature | 0~50°C/ -20~60°C (option) |
| Power | DC 9~36V |
| Notes | CE/FCC Class A |
