Caratteristiche Tecniche
| CPU | Broadcom BCM2711, ARM Cortex-A72 (4x Cores, up to 1.5GHz) |
|---|---|
| Chipset | – |
| RAM | Onboard DDR4 4GB SDRAM |
| LAN | 1 x GbE LAN, RJ45 |
| I/O | “2 x USB 2.0 type A 1 x USB Download Mode, Micro USB 1 x 2 x 5pin External Terminal Block with 2 x COM 1 x RS232(TX, RX, RTS, CTS) /485, 1 x RS232(TX, RX, RTS, CTS) |
| Storage | 16GB/32GB eMMC Flash |
| Expansion | 1 x Half / Full-size mPCIe slot with micro SIM slot |
| Display Size and Form Factor | 7″, – |
| Resolution | 800-480 px |
| Brightness | 400 cd/m2 |
| Touch | PCAP |
| Mechanicals | IP65 compliant front beze, VESA Mount 75×75, Panel Mount |
| Operating Temperature | 0~50°C/ -20~60°C (option) |
| Power | DC 9~36V |
| Notes | CE/FCC Class A |
