Caratteristiche Tecniche
| CPU | Ti-AM3354, ARM Cortex A8(1x Core,1.0GHz) |
|---|---|
| Chipset | – |
| RAM | Onboard 512MB DDR3 SDRAM |
| LAN | 1 x 10/100MB LAN RJ-45 (POE for option) |
| I/O | USB 2 x USB 2.0 type A; Serial / Parallel 1 x RS-232/422/485 DB9 , default RS-232, 1 x Line-out |
| Storage | Onboard 512MB NAND Flash (1GB for option) |
| Expansion | 1 x mini-PCIe slot (full size) |
| Display Size and Form Factor | 7″, – |
| Resolution | 800 x 480 px |
| Brightness | 350 cd/m2 |
| Touch | PCAP |
| Mechanicals | IP65 compliant front bezel,VESA Mount 75×75, Panel Mount |
| Operating Temperature | 0~50°C/ -20~60°C (option) |
| Power | DC 9~36V |
| Notes | CE/FCC Class A/UL |
