Caratteristiche Tecniche
| CPU | NXP i.MX8M Quad Plus, 4x Cortex-A53 1.8 GHz |
|---|---|
| Chipset | – |
| RAM | Onboard 4GB LPDDR4-3200MHz SDRAM |
| LAN | 1 x M12 Female, 8-pin for 1 x GbE LAN |
| I/O | 1 x M12 Female, 8-pin for 2 x USB2.0, 1 x M12 Female, 8-pin for RS-232/422/485, 1 x M12 Female, 8-pin for 2-ch CAN BUS, 4 x SMA connectors’ holes for external antennas |
| Storage | Onboard 32GB eMMC NAND Flash |
| Expansion | 1 x Full-size mini-PCIe socket (USB2.0) for HSUPA/LTE Module (for option), 1 x Full-size mini-PCIe socket (PCIe+USB2.0) for WIFI/BT Module (for option) |
| Display Size and Form Factor | 10.1″, 16/10 |
| Resolution | 1280 x 800 px |
| Brightness | 350 cd/m2 |
| Touch | Capacitive |
| Mechanicals | IP66, VESA Mount |
| Operating Temperature |
0~50°C WT1: -20°C~60°C for option, WT2 : -20~70°C for option |
| Power | DC 9~60V |
| Notes | – |
