General Features
| CPU | 11th Gen Intel® Processor |
|---|---|
| Chipset | – |
| RAM | Memory Down up to 16GB Single Channel LPDDR4X 4266MHz |
| LAN | 1 x Intel® Ethernet I225IT (10M/100M/1000M/2.5Gbps) |
| I/O | USB 2 x USB 3.2 Gen.2 8 x USB 2.0 |
| Storage | SATA 2 x SATA 3.0 (up to 6Gb/s) NVMe SSD 1 x 64GB/128GB/256GB/512GB/1024GB on board SSD (available upon request) |
| Expansion | 1 x PCIe x4 (Gen 3) 1 x I2C 1 x SMBus 2 x SPI 2 x UART (TX/RX) |
| Operative range | -40 to 85°C |
| Power | 4.75V~20V, 5VSB, VCC_RTC (ATX mode) 4.75V~20V, VCC_RTC (AT mode) |
| Notes | – |
