General Features
| CPU | NXP i.MX8X series processors |
|---|---|
| Chipset | – |
| RAM | Single Channel, LPDDR4 Memory Down up to 4GB |
| LAN | 1 x GigE LAN |
| I/O | 3 x USB 3.0, 1 x USB 2.0 (OTG), 1 x 4-bit SDIO, 1 x CAN |
| Storage | 2 x SATA (6 Gb/s), 1 x eMMC up to 32GB |
| Expansion | 1 x PCIe x1 |
| Operative range | 0°C to 60°C, -20 to 70°C (Option) |
| Power | 5V DC |
| Notes | – |
