Technical Features
| CPU | 12th Generation Intel® LGA 1700 Socket Processors |
|---|---|
| Chipset | Intel® R680E/Q670E Chipset |
| RAM | Four 288-pin UDIMM up to 128GB |
| LAN | 2 x Intel® I225LM, 2 x Intel® x550-AT2 |
| I/O | 4 x USB 3.2 Gen2, 4 x USB 3.2 Gen1, 2 x RS-232/422/485, 4 x RS-232 |
| Storage | 2 x M.2 2242/2260/2280 M key, 4 x SATA 3.0 (up to 6Gb/s) |
| Expansion | 1 x PCIe x16 (Gen 5), 3 x PCIe x4 (Gen 4), 1 x PCIe x4 (Gen 4) (Default, co-lay M.2 M key), 2 x PCI |
| Operative range | -5° + 65° C |
| Power | ATX |
| Notes | – |
