Technical Features
| CPU | Single Socket E (LGA-4677) 4th Gen Intel® Xeon® Scalable processors |
|---|---|
| Chipset | Intel® C741 |
| RAM | 8 x DIMMs; Supports 3DS DDR5 RDIMM. Up to 4800 MT/s |
| LAN | 2 x 1GbE BaseT with Intel® i210, 1 x RJ45 Dedicated IPMI LAN port |
| I/O | 4 x USB 3.2 Gen 1 port(s)(2 rear; 2 headers), 3 x USB 2.0 port(s)(2 rear; 1 Type A), 2 x COM Port(s) (1 header; 1 rear), 1 x VGA port |
| Storage | 8 x 3.5″ NVMe/SATA/SAS drive bays (4x 3.5″ NVMe hybrid), 1 x M.2 PCIe 3.0 x2 NVMe |
| Expansion | 2 x PCIe 5.0 x16 FHFL, 2 x PCIe 5.0 x8 LP |
| Operative range | 10°C ~ 35°C |
| Power | 1U 920W redundant power supply |
| Notes | – |
