Technical Features
| CPU | Dual Socket E (LGA-4677) 4th Gen Intel® Xeon® Scalable processors |
|---|---|
| Chipset | Intel® C741 |
| RAM | 32 x DIMM slots supporting up to 8TB of memory, RDIMMs up to DDR5-4800 |
| LAN | 1 x RJ45 Dedicated BMC LAN port |
| I/O | 2 x USB 2.0 port(s) (2 rear), 1 x VGA port(s) |
| Storage | 8 x 2.5″ hot-swap NVMe/SATA/SAS drive bays, RAID support via RAID Controller AOC, 2 x internal M.2 NVMe/SATA drive slots |
| Expansion | Optional PCIe slot configurations up to 8 x PCIe 5.0 x8 or 4 x PCIe 5.0 x16 slots with support for double-width GPU/Accelerator cards |
| Operative range | 10°C ~ 35°C |
| Power | 1U 800W/1200W Redundant Titanium CRPS w/PMBus power supply |
| Notes | support for double-width GPU/Accelerator cards |
