Technical Features
| CPU | 3rd Gen Intel® Xeon® Scalable Processors |
|---|---|
| Chipset | C621A Chipset |
| RAM | 16 DIMM slots Up to 4TB: 16x 256 GB DRAM and 8x 512 GB PMem Memory Type: 3200/2933/2666MHz ECC DDR4 RDIMM/LRDIMM Intel® Optane™ persistent memory 200 series |
| LAN | 2x 10GbE BaseT port(s), 1 x ASPEED AST2600 BMC |
| I/O | 4 x USB 3.2 Gen2 port(s) (2 rear type A; 2 Others front panel), 1 x COM Port(s) (1 header) |
| Storage | 4 x 2.5″ hot-swap NVMe/SATA/SAS drive bays (2x 2.5″ NVMe dedicated), 1 x M.2 NVMe OR 1 x M.2 SATA3 |
| Expansion | 4 x PCI-E 4.0 x16 (FHFL), 2 x PCI-E 4.0 x16 (LP) |
| Operative range | 10°C ~ 35°C (50°F ~ 95°F) |
| Power | 2000W Redundant Power Supplies with PMBus |
| Notes | – |
