4U8G-ICX2/2T
Request Information
Technical Features
| CPU | support 3rd Gen Intel® Xeon® Scalable Processors |
|---|---|
| Chipset | C621A Dual Socket |
| RAM | RDIMM: up to 64GB, LRDIMM: up to 256GB, NVDIMM: up to 32GB |
| LAN | 2 RJ45 (10GbE, 1 dedicated IPMI LAN |
| I/O | 4 x USB Type-A (USB3.2 Gen1), 1 DB15 (VGA) |
| Storage | “12 Hot-swap 3.5” drive bays, supports 2 SATA drives; additional 4-8 SATA drives possible by cable reconfiguration, supports 8 SAS/SATA drives by additional PCIe 8-port RAID/HBA card, 1 M-key (PCIe3.0 x4/SATA) supports 22110/2280 form factor, 1 optional M-key (PCIe3.0 x4/SATA) supports 22110/2280 form factor |
| Expansion | 8x PCle x16 slot, Front side 1 FHHL PCIe3.0 x4 and OCP NIC 3.0 |
| Operative range | Operation temperature: 10°C ~ 35°C |
| Power | Atx |
| Notes | – |
