General Features
| Class | L2 Managed |
|---|---|
| Network Ports | 8 x 10/100BASE-TX RJ45; 4 x FX/GbE SFP |
| I/O Ports | 1 x RJ45 Console Port; 1 x USB Port |
| Certifications |
DNVGL-CS-0339:2016, DNVGL-RU-SHIP-Pt4Ch9:2018, IEC-60945, IACS E10 (Rev.6 2014); LR certify environmental category ENV1, ENV2, and ENV3 |
| Mechanicals | IP30 Aluminium Case, DIN Rail Mounting |
| Operating Temperature | -40°C ÷ 75°C |
| Power | Primary inputs: 12-48V DC; Redundant inputs: 12-48V DC |
| Notes | 1 x Console Port for command-line interface and USB port supports firmware upgrade, keeps configuration settings safe, and downloads log files; it helps users to monitor the network devices with a Topology Map, is compatible with third-party devices, and supports communication with legacy and advanced industrial devices; it optimizes network performance with Storm and Flow Control and QoS for enough bandwidth; DNV GL Marine Approval, communication standards for safe and reliable marine operations |
