General Features
| CPU | Onboard Intel 6th Gen. Core i3/i5 (Option) |
|---|---|
| Chipset | – |
| RAM | 1 x 260Pin SO-DIMM DDR4 up to 16GB 2133MHz |
| LAN | 1 x GigE M12 |
| I/O | 1 x USB 2.0 M12, 1 x COM (RS232/422/485) M12 |
| Storage | 1 x SATA (6 Gb/s) |
| Expansion | 1 x mPCIe |
| Display Size and Form Factor | 17″, 5:4 |
| Resolution | 1280 x 1024 px |
| Brightness | 350 cd/m2, 1000 cd/m2 (H) |
| Touch | PCAP (P), Resistive (R) |
| Mechanicals | Full IP66/IP69K Stainless Steel Case, VESA Mount, Yoke Mount |
| Operating Temperature | 0°C to 50°C |
| Power | 9-36V DC |
| Notes | – |
