Technical Features
| CPU | Intel Elkhart Lake Celeron J6412, Quad-core 2.0Ghz, burst to 2.6Ghz |
|---|---|
| Chipset | – |
| RAM | SO-DIMM, DDR4, max. up to 16GB |
| LAN | 4 x RJ45, LAN 1~3 ports Support PoE 802.3 AF (Single port max. up to 15.4W, total less than 45W); LAN 4 support standard 10/100/1000 Mbps |
| I/O | 2 x USB3.0, 2 x USB2.0, 2 x RS232 |
| Storage | 1 x M.2 M-key 2242/2280 SATA SSD |
| Expansion | 1 x M.2 2230 E-key slot for Wi-Fi, 1 x Mini-PCIe slot |
| Display Size and Form Factor | 21.5″, – |
| Resolution | 1920 x 1080 px |
| Brightness | 250 cd/m2 |
| Touch | PCAP |
| Mechanicals | IP65 Front Panel,VESA 75/100, Panel Mount |
| Operating Temperature | 0 ～ +60℃ |
| Power | DC 9~36V |
| Notes | CE/FCC Class A |
