Technical Features
| CPU | Intel Celeron J6412 Processor (2.0 GHz, 1.5MB L2 cache) |
|---|---|
| Chipset | Intel SoC |
| RAM | 1 x 260-pin SO-DIMM up to 32GB DDR4 3200MHz |
| LAN | 1 x 2.5 x GbE LAN RJ-45(I226) |
| I/O | 2 x USB 3.2 Gen2 type A; 2 x USB 2.0 type A; 1 x RS-232/422/485 (Default RS-232; select via BIOS); 1 x DP, support DP++ |
| Storage | 1 x M.2 B-Key slot (Support SATA3; 2242) |
| Expansion | 1 x Mini-PCIe slot (full size); 1 x M.2 E-key; 1 x Nano SIM card holder |
| Display Size and Form Factor | 7″ TFT-LCD |
| Resolution | 800 x 480 px |
| Brightness | 350 cd/m2 |
| Touch |
Projected Capacitive Touch (for BP model); Resistive Touch (for BR model |
| Mechanicals | SUS304 Stainless Steel Front Bezel (default); SUS316L Stainless Steel Front Bezel (for option); Aluminum Die-casting Back Cover; Panel Mount, VESA Mount 100 x 100; IP66/IP69K Compliant Front Bezel |
| Operating Temperature | 0°÷50˚C/ -20°÷60°C (option) |
| Power | DC 9÷36V |
| Notes | CE/FCC Class B/ EN 1672-2 Compliant for P Model (optional) |
