General Features
| CPU | Intel® Core™ i7-6700/i7-6700TE/i5-6500/i5-6500TE/i3-6100/i3-6100TE Processor (Skylake-S) |
|---|---|
| Chipset | Intel® Q170 |
| RAM | 2 DDR4 2133 MHz SO-DIMM, up to 32GB |
| LAN | 2 Independent GigE LAN, iAMT 11.0 supported |
| I/O | 7 x USB 3.0, 4 x COM RS-232/422/485, 32 Isolated DIO |
| Storage | 4 x 2.5″ SSD/HDD Bracket, 1 x CFast Socket |
| Expansion | 3 x mPCIe, 4 x PCI |
| Operative range | Depends On CPU |
| Power | 6V to 36V DC Power Input with 80V Surge Protection, Configurable Ignition Power Control |
| Notes | – |
