General Features
| CPU | 7th generation Intel® Xeon®/Core™ i7 Processor(Kaby Lake) |
|---|---|
| Chipset | Intel® C236 |
| RAM | 2 DDR4 2133MHz SO-DIMM, up to 32GB |
| LAN | 2 Independent GigE LAN, iAMT 11.0 supported |
| I/O | 7 USB 3.0, 32 Isolated DIO, 4 COM RS-232/422/485 (ESD 8KV) |
| Storage | 4 Front-access 2.5″ SSD/HDD Tray, 1 CFast Socket |
| Expansion | 2 PCI/PCIe Slot, 3 Mini PCIe |
| Operative range | Depends On CPU |
| Power | 10V to 36V DC Power Input w/80V Surge Protection, Configurable Ignition Power Control |
| Notes | – |
