General Features
| CPU | 8th/9th generation Intel Core i7/i5/i3 processors (up to 65W) |
|---|---|
| Chipset | Intel® Q370 |
| RAM | 2 x SO-DIMM DDR4 2400/2666MHz up to 32GB |
| LAN | 2 x GigE RJ45 |
| I/O | 4 x USB 3.1, 3 x USB 2.0, 2 x COM (RS232/422/485), 2 x COM (RS232), 2 x DI Opto-isolated, 2 x DO Opto-isolated |
| Storage | 1 x M.2 Key M, 2 x SATA (6 Gb/s) |
| Expansion | 1 x M.2 Key E, 1 x mPCIe |
| Operative range | 0°C – 50°C |
| Power | 12V DC input (9-28V Wide Range DC Input with integrated UPS option) |
| Notes | – |
