mii170-1xPCIex8+1PCIex4
Request Information
General Features
| CPU | Intel® Skylake/Kaby Lake LGA 1151 for i7/i5/i3, 65W/35W processor |
|---|---|
| Chipset | Intel® Q170 |
| RAM | 2 x 256-pin, DDR4 2133MHz up to 32GB, ECC support |
| LAN | 2 x GigE RJ45 |
| I/O | 5 x COM RS232, 1 x COM RS 232/422/485, 2 DI Isolated, 2 DO Isolated, 4 x USB 3.0, 3 x USB 2.0 |
| Storage | 2 x 2,5” SATA 6Gb/s, w/ RAID 0/1/5/10, 1 x CFast socket |
| Expansion | 1 x PCIe x8, 1 x PCIe x4, 2 x mPCIe |
| Operative range | 0°C to +50°C |
| Power | Wide input voltage range DC 9-28V, Intagrated UPS, Remote Power Button |
| Notes | – |
