General Features
| CPU | 7th generation Intel® Xeon®/Core™ i7/i5/i3 Processor (Kaby Lake) |
|---|---|
| Chipset | Intel® C236 |
| RAM | 2 DDR4 2133MHz SO-DIMM, up to 32GB (ECC/Non-ECC) |
| LAN | 2 x GigE RJ45 |
| I/O | 32 Isolated DIO, 6 USB 3.0, 4 COM RS-232/422/485 |
| Storage | 2 Front-access 2.5″ SSD Tray, 1 CFast Socket |
| Expansion | 1 PCI/PCIe, 3 Mini PCIe, Optional SUMIT A, B, MXM |
| Operative range | -25°C to 60°C |
| Power | 10V to 36V DC-in, 80V Surge Protection, Configurable Ignition Power Control |
| Notes | 1 PCI o 1 PCIe |
