General Features
CPU 12th Gen Intel® Core™ i9/i7/i5/i3 Processor (Alder Lake-S)
Chipset Intel® R680E
RAM Dual Channel DDR4 3200MHz SO-DIMM, up to 64GB
LAN 2 x 10GigE, 4 x 2.5GigE IEEE 802.3at (25.5W/48V) PoE+, 1 x 2.5GigE, 1 x GigE
I/O 6 x USB 3.2 Gen 2, 2 x COM (RS-232/422/485), 8 x Isolated DI, 8 x Isolated DO
Storage 2 x SATA3 (6 Gb/s), 1 x M.2 Key M, 1 x mSATA
Expansion 1 x mPCIe, 1 x M.2 Key B, 1 x M.2 Key E
Operative range Depends on CPU
Power 9V to 50V DC Power Input with 80V Surge Protection, Configurable Ignition Power Control
