General Features
| CPU | Intel® Xeon® E3-1505M v5/Core™ i7-6820EQ/i5-6440EQ Processor (Skylake-H) |
|---|---|
| Chipset | Intel® CM236 |
| RAM | 2 DDR4 2133MHz SO-DIMM, up to 32GB (ECC/Non-ECC) |
| LAN | 6 Independent GigE LAN with 4 IEEE 802.3at PoE+, 4-port 10 GigE LAN, up to 10Gbps data rate |
| I/O | 32 Isolated DIO, 6 USB 3.0, 4 COM RS-232/422/485 (ESD 8KV) |
| Storage | 2 2.5″ SSD Tray, 1 CFast |
| Expansion | 4 Mini PCIe/mSATA |
| Operative range | -40°C to 55°C |
| Power | 6V to 36V DC-in with 80V Surge Protection, Configurable Ignition Power Control |
| Notes | – |
