General Features
| CPU | Intel® Xeon® E3-1505M v5/Core™ i7-6820EQ/i5-6440EQ Processor (Skylake-H) |
|---|---|
| Chipset | Intel® CM236 |
| RAM | 2 DDR4 2133/ 1866 MHz SO-DIMM, up to 32GB |
| LAN | 6 Independent GigE LAN with 4 IEEE 802.3at PoE+, iAMT 11.0 supported |
| I/O | 6 x USB 3.0, 4 x COM RS-232/422/485, 32 Isolated DIO |
| Storage | 2 x 2.5″ SSD Tray, 1 x CFast Socket |
| Expansion | 1 x PCIe, 4 x mPCIe, 2 x SUMIT |
| Operative range | -25°C to 70°C |
| Power | 6V to 36V DC-in, 80V Surge Protection, Configurable Ignition Power Control |
| Notes | – |
