General Features
| CPU | Intel® Xeon® E3-1505M v5/ Core™ i7-6820EQ/ i5-6440EQ Processor (Skylake-H) |
|---|---|
| Chipset | Intel® CM236 |
| RAM | 2 DDR4 2133/ 1866 MHz SO-DIMM, up to 32GB |
| LAN | 6 Independent GigE LAN with 4 IEEE 802.3at PoE+, iAMT 11.0 supported |
| I/O | 6 USB 3.0, 16 Isolated DIO, 4 COM RS-232/422/485 |
| Storage | 2 2.5″ SSD Tray, 1 CFast |
| Expansion | 1 PCI slot, 4 Mini PCIe/mSATA |
| Operative range | -25°C to 70°C |
| Power | 6V to 36V DC-in, 80V Surge Protection, Configurable Ignition Power Control |
| Notes | – |
