General Features
| CPU | Intel® Core™ i7-6700/i7-6700TE/i5-6500/i5-6500TE/i3-6100/i3-6100TE Processor (Skylake-S) |
|---|---|
| Chipset | Intel® C236 |
| RAM | 2 DDR4 2133MHz SO-DIMM, up to 32GB |
| LAN | 4 Independent GigE LAN, iAMT 11.0 supported |
| I/O | 6 x USB 3.0, 4 x COM RS-232/ 422/ 485, 16 GPIO |
| Storage | 2 x 2.5″ SSD/ HDD Bracket, 1 x CFast Socket, 1 x M2DOM |
| Expansion | 3 x mPCIe, 2 x SUMIT |
| Operative range | Depends On CPU |
| Power | 6V to 36V DC Power Input with 80V Surge Protection, Configurable Ignition Power Control |
| Notes | – |
