Technical Features
| CPU | NVIDIA® Jetson Orin™ NX |
|---|---|
| Chipset | – |
| RAM | up to 16GB LPDDR5 DRAM |
| LAN | 2 x LAN 10/100/1000 Base-T Ethernet GigE LAN, RJ45 Connector (Optional X-coded M12 Connector) |
| I/O | 1 x USB 3.1 Gen 2, 2 x USB 3.1, 1 x CAN, 2 COM RS-232/422/485, 7-bit GPIO |
| Storage | 1 x M.2 Key M 2280 NVMe SSD 128GB, 1 x micro SD (External) |
| Expansion | 2 x M.2 Key B Socket (3042/3052, USB3), 1 x M.2 Key E Socket (2230, PCIe/USB) |
| Operative range | 15W TDP Mode: -25°C to 70°C, 25W TDP Mode: -25°C to 55°C |
| Power | 9V to 50V DC Power Input |
| Notes | – |
