Technical Features
| CPU | EAC-5000-R32 : 8-core Arm® Cortex®-A78AE v8.2 64-bit CPU EAC-5000-R64 : 12-core Arm® Cortex®-A78AE v8.2 64-bit CPU |
|---|---|
| Chipset | Intel® SoC |
| RAM | Up to 32GB LPDDR5 RAM |
| LAN | 2 x 10/100/1000 Base-T Ethernet GigE LAN, RJ45 Connector (Optional X-coded M12 Connector) |
| I/O | 4 x USB 3.1; 1 x USB 3.2 Gen 2; 1 x Micro USB console debug port; 1 x Micro USB OS flash port; 2 COM RS-232/ 422/ 485; 16 x Isolated DIO: 8 x DI, 8 x DO; 2 x Isolated CAN Bus support CAN FD; 2 x SIM Card Socket |
| Storage | 2 x M.2 Key M Socket (2280, PCIe Gen3 x4); 1 x eMMC 5.1, 64GB; 1 x Micro SD (External) |
| Expansion | 1 x PCIe x16 Slot with PCIe 3.0 x8 signal; 1 x M.2 Key B Socket (3042/3052, USB3); 1 x M.2 Key E Socket (2230, PCIe/USB) |
| Operative range | 30W TDP Mode: -25°C ÷ 70°C with 0.63 m/s air flow 40/50W TDP Mode: -25°C ÷ 55°C with 0.63 m/s air flow |
| Power | DC 9V ÷ 50V wide range power input, Ignition Power Control |
| Notes | GMSL Cameras |
