General Features
| CPU | Intel® Core™ i7/i5/i3 U-series Processor (Kaby Lake-U/Skylake-U) |
|---|---|
| Chipset | – |
| RAM | 2 DDR4 2133MHz SO-DIMM, up to 32GB |
| LAN | 3 Independent GigE LAN with 2 M12 IEEE 802.3at PoE+ |
| I/O | 4 x USB 3.0, 3 x COM RS-232/422/485 with 1 Isolated, 32 GPIO |
| Storage | 2 x 2.5″ SSD/HDD Bracket, 1 x CFast Socket |
| Expansion | 2 x mPCIe |
| Operative range | -40°C to 70°C |
| Power | 6V to 36V DC-in with 80V Surge Protection, Ignition Power Control |
| Notes | – |
