Ultra-Compact Systems

Ultra-Compact Systems offer a high number of I/O ports in an extremely small space, plus a PCI or PCIe slot.
These systems are characterized by scalable performance and low power consumption, thanks to the use of Intel™ Atom processors.
All systems in this category can be used in extended temperature range applications.

13th Gen Intel® Core i7/i5/i3

	Model	LAN	USB 2.0	USB 3.0	USB 3.1	USB 3.2	Type C	M.2	COM	PCI	PCIe	Mini PCIe	DIO	Power		DM
	ABP-4000	2	2	-	-	3	-	4	2	-	-	-	-	9-55V

13th Gen Intel® Core i7

	Model	LAN	USB 2.0	USB 3.0	USB 3.1	USB 3.2	Type C	M.2	COM	PCI	PCIe	Mini PCIe	DIO	Power		DM
	ECS-4700F-PoER	6	2	-	-	3	-	2	4	-	-	-	16	9-50V
	ECS-4700F-PoE	6	2	-	-	3	-	2	4	-	2	-	16	9-50V
	ECS-4700-PoER	6	2	-	-	3	-	2	4	-	-	-	16	9-50V
	ECS-4700-PoE	6	2	-	-	3	-	2	4	-	-	-	16	9-50V
	ECS-4700-2G	2	2	-	-	3	-	2	4	-	-	-	16	9-50V

Rockchip RK3399

	Model	LAN	USB 2.0	USB 3.0	USB 3.1	USB 3.2	Type C	M.2	COM	PCI	PCIe	Mini PCIe	DIO	Power		DM
	EIC-1000	1	1	-	1	-	-	-	2	-	-	1	-	9-55V

NVIDIA® JETSON Orin NX

	Model	LAN	USB 2.0	USB 3.0	USB 3.1	USB 3.2	Type C	M.2	COM	PCI	PCIe	Mini PCIe	DIO	Power		DM
	RAC-1000	2	-	-	2	-	-	2	2	-	-	-	-	9-50V
	EAC-6000	2	-	-	2	-	-	3	2	-	-	-	-	9-50V
	EAC-4000	1	-	-	4	-	-	1	2	-	-	1	-	12V

NVIDIA Jetson Xavier NX - ARMv8-A

	Model	LAN	USB 2.0	USB 3.0	USB 3.1	USB 3.2	Type C	M.2	COM	PCI	PCIe	Mini PCIe	DIO	Power		DM
	EC100-XNX	9	-	-	-	2	-	-	-	-	-	1	9	54V
	EAC-2100	4	-	-	4	-	-	3	2	-	-	-	-	9-50V
	EAC-3000	5	-	4	-		-	3	2	-	-	-	-	9-50V
	EAC-2000	4	-	-	4	-	-	3	2	-	-	-	-	9-50V

Foxconn Cortex A53 - ARMv8-A

	Model	LAN	USB 2.0	USB 3.0	USB 3.1	USB 3.2	Type C	M.2	COM	PCI	PCIe	Mini PCIe	DIO	Power		DM
	VAC-1100	1	-	2	-	-	-	1	-	-	-	-	-	9-55V
	VAC-1000	1	-	2	-	-	-	1	-	-	-	-	-	9-55V

NXP iMX8 Cortex A53 - ARMv8-A

	Model	LAN	USB 2.0	USB 3.0	USB 3.1	USB 3.2	Type C	M.2	COM	PCI	PCIe	Mini PCIe	DIO	Power		DM
	EIC-2000	2	-	2	-	-	-	1	-	-	-	1	-	9-55V

NXP iMX6 Cortex A7 - ARMv7-A

	Model	LAN	USB 2.0	USB 3.0	USB 3.1	USB 3.2	Type C	M.2	COM	PCI	PCIe	Mini PCIe	DIO	Power		DM
	AIC-110	2	1	-	-	-	-	-	2	-	-	1	12	9-50V
	AIC-100	2	1	-	-	-	-	-	2	-	-	1	-	9-50V

11th Gen i3/i5/i7 Intel® Core

	Model	LAN	USB 2.0	USB 3.0	USB 3.1	USB 3.2	Type C	M.2	COM	PCI	PCIe	Mini PCIe	DIO	Power		DM
	SPC-7100	2	4	-	2	-	-	3	2	-	-	-	-	9-55V
	SPC-7000	2	4	-	2	-	-	3	2	-	-	-	-	9-55V

8th Gen i3/i5/i7 Intel® Core

	Model	LAN	USB 2.0	USB 3.0	USB 3.1	USB 3.2	Type C	M.2	COM	PCI	PCIe	Mini PCIe	DIO	Power		DM
	ABP-3000	4	-	-	4		-	4	4	-	-	1	16	9-50V
	SPC-5200	4	-	-	4		-	-	4	-	-	1	16	9-48V
	SPC-5100	2	-	-	4		-	-	2	-	-	2	-	9-48V
	SPC-5000	2	-	-	4		-	-	2	-	-	2	-	9-48V

6/7th Gen i3/i5/i7 Intel® Core

	Model	LAN	USB 2.0	USB 3.0	USB 3.1	USB 3.2	Type C	M.2	COM	PCI	PCIe	Mini PCIe	DIO	Power		DM
	ARS-2000ML	3	-	4	-		-	-	4	-	-	2	32	6-36V
	ARS-2000L	3	-	4	-		-	-	4	-	-	2	32	6-36V

6th Gen i3/i5/i7 Intel® Core

	Model	LAN	USB 2.0	USB 3.0	USB 3.1	USB 3.2	Type C	M.2	COM	PCI	PCIe	Mini PCIe	DIO	Power		DM
	ECS-4500-PoE	6	3	5	-		-	-	4	-	-	2	16	6-36V
	ECS-4500-PDR	2	3	5	-		-	-	4	-	-	2	16	9-36V
	ECS-4500-2R	2	3	5	-		-	-	4	-	-	2	16	6-36V
	ECS-4500-2G	2	3	5	-		-	-	4	-	-	2	16	6-36V
	SPC-3530	4	4	4	-		-	-	9	-	-	2	16	9-36V
	SPC-3520	4	4	4	-		-	-	5	-	-	2	16	9-36V
	SPC-3510	2	4	4	-		-	-	2	-	-	2	16	12-36V

Intel ® Celeron

	Model	LAN	USB 2.0	USB 3.0	USB 3.1	USB 3.2	Type C	M.2	COM	PCI	PCIe	Mini PCIe	DIO	Power		DM
	AVS-302	4	3	1	-	-	-	-	2	-	-	1	8	9-36V

Intel® Atom Elkhart Lake

	Model	LAN	USB 2.0	USB 3.0	USB 3.1	USB 3.2	Type C	M.2	COM	PCI	PCIe	Mini PCIe	DIO	Power		DM
	SPC-6000	2	2	-	2	-	-	3	4	-	-	-	-	12V
	PBC-1000	2	-	-	2	-	-	2	2	-	-	-	-	12V
	ESP-1000	2	2	-	2	-	-	2	4	-	-	-	-	9-55V
	AVS-320	3	2	-	2	-	-	2	2	-	-	-	8	24V
	ACS-2310A	2	-	-	-	2	-	2	1	-	-	1	-	9-36V

Intel® Atom Apollo Lake

	Model	LAN	USB 2.0	USB 3.0	USB 3.1	USB 3.2	Type C	M.2	COM	PCI	PCIe	Mini PCIe	DIO	Power		DM
	SPC-4600	2	-	4	-		-	-	4	-	-	2	16	9-36V
	SPC-4500	2	-	4	-		-	-	4	-	-	2	-	12V
	SPC-4020A	2	4	2	-		-	1	4	-	-	3	16	9-36V
	SPC-4020	2	4	2	-		-	1	4	-	-	3	16	12V
	SPC-4010	2	4	2	-		-	-	2	-	-	2	-	12V
	EC800-AL	2	2	2	-		-	-	2	-	-	1	-	9-36V

Intel® Atom Bay Trail

	Model	LAN	USB 2.0	USB 3.0	USB 3.1	USB 3.2	Type C	M.2	COM	PCI	PCIe	Mini PCIe	DIO	Power		DM
	AVS-313	3	5	1	-		-	-	1	-	-	1	32	24V
	SPC-2845X	2	-	4	-		-	-	4	-	-	2	8	6-36V
	SPC-2845RS	2	-	4	-		-	-	4	-	-	2	8	6-36V
	SPC-2845R	2	-	4	-		-	-	4	-	-	2	8	6-36V
	SPC-2845	2	-	4	-		-	-	4	-	-	2	8	6-36V
	ABP-2845	2	2	3	-		-	-	6	-	-	2	8	9-28V
	AVS-310	3	1	1	-		-	-	2	-	-	1	-	24V
	AVS-300	2	2	2	-		-	-	5	-	-	1	8	9-36V
	uBOX-110	2	1	1	-		-	-	-	-	-	1	-	12V
