Technical Features
| CPU | 12th Gen Intel® Core™ i9/i7/i5/i3 Processor (Alder Lake-S), 13th Gen Intel® Core™ i9/i7/i5/i3 Processor (Raptor Lake-S) |
|---|---|
| Chipset | Intel® H610E |
| RAM | 2 x DDR5 4800MHz SO-DIMM, up to 64GB (Non-ECC) |
| LAN | 2 x Intel GigE |
| I/O | 4 x USB 3.1 (external), 4 x USB 2.0 (external), 2 x USB 2.0 (internal), 2 x COM RS (232/422/485) |
| Storage | 1 x SATA3 (6 Gb/s), 1 x M.2 Key M, 1 x SSD/HDD 2,5″ |
| Expansion | 1 x M.2 Key B, 1 x M.2 Key E |
| Operative range | 35W CPU Fanless: -25°C to 60°C (-13°F to 140°F), 65W CPU Fanless: -25°C to 45°C (-13°F to 113°F) |
| Power | 24V DC Power Input, Configurable Ignition Power Control |
| Notes | – |
