Caratteristiche Tecniche
| CPU | Intel® Core™ Ultra 7 165U Processor (12 Cores) Intel® Core™ Ultra 5 135U Processor (12 Cores) |
|---|---|
| Chipset | Intel® SoC |
| RAM | 1 x DDR5 5600MHz SO-DIMM, up to 48GB |
| LAN | 2 x Intel® I226 2.5GigE LAN supports TSN |
| I/O | 2 x USB 3.2 Gen 2 Type-A; 1 x USB 3.2 Gen 2×2 Type-C; 2 x COM RS-232/422/485; 1 x HDMI 2.1 : Up to 4096×2304 @60Hz; 1 x DisplayPort 1.4 : Up to 4096 x 2304 @60Hz; 1 x DisplayPort 1.4 : Up to 3840 x 2160 @60Hz by USB Type-C; 1 x External Nano SIM Card Socket |
| Storage | 1 x M.2 Key M Socket, 1 x M.2 Key B Socket, 1 x SATA III (6Gbps) |
| Expansion | 1 x M.2 Key B Socket (3042/3052, PCIe x2/USB 3, default/USB 2); 1 x M.2 Key E Socket (2230, PCIe x1/USB 2); 1 x SATA III (6Gbps) with internal 2.5″ HDD/SSD bracket |
| Operative range | -40°C ÷ 60°C |
| Power | 9V ÷ 55V, 16-mode Software Ignition Control |
| Notes | – |
