Caratteristiche generali
| CPU | Intel® Celeron® J6412 CPU Elkhart Lake (2.0GHz/2.6GHz) |
|---|---|
| Chipset | – |
| RAM | Single Channel DDR4 SO-DIMM 3200MHz, up to 32GB |
| LAN | 1 x Intel I210AT GbE controller; 3 x Intel I226-V 2.5GbE controllers |
| I/O | 2 x USB3.1; 2 x USB2.0; 2 x RS232/422/485(default RS-232) with auto flow control; 1 x HDMI up to 4096 x 2160 @ 24 Hz; 1 x DP up to 4096 x 2160 @ 60 Hz; |
| Storage | 1 x SDRAM DDR4 3200 MHz SO-DIMM slot (max. 32G); 4GB DDR4 SO-DIMM pre-installed*(CTOS) |
| Expansion | 1 x E-Key M.2 2230 slot (PCIe/USB2.0 signal supported); 1 x M.2 2; 1 x Mini-PCIe slot (PCIe/ USB2.0 signal supported); 1 x SIM Card socket for 3G/4G module; 1 x 8bit programmable GPIO (default 3.3V, 5V optional) (optional by internal pin head) |
| Operative range | -20°C ÷ 60°C |
| Power | 12÷24V DC, 2-pin Phoenix connector |
| Notes | – |
